​Key features:

H series on-line UPS is an advanced true double conversion on-line topology, the H series isolated gate bipolar transistors (IGBT) for true isolation from AC input. Ideal for data centers in network and industrial applications. Features scalable battery packs for those critical business systems that require long run times. With the H series wide in-put voltage range and near zero tolerance on frequency and voltage variance on the put-put the H series is perfect for the most demanding and delicate of applications.

►Sine-wave output
True sine-wave output with less than 3% THD

►Double conversion design
Zero transfer/complete isolation of input AC

►UPS monitoring software
Powerful true RS232 communication via the enclosed software manages and safely shutdown operating systems.

►Network RJ45/11 protection
Completed powerful network and phone line surge protection

►AC surge suppressor
Powerful multi-stage surge components exceed IEEE requirements.

►SNMP slot option
Allows for remote monitoring and control via www

►Sleep mode
Worry free battery management. The unit turns itself off after ten seconds to conserve battery power when no power needs are detected.

►Battery level indicators
LED's indicate battery levels

►Load sensing
The incorporated LED load indicators allow IT professionals to manage backup time and balance power loads.

►Low battery indicators
The low battery level indicator will warn of eminent UPS shutdown two full minutes before unit shuts down.

►Replace battery indicators
A preventative measure that indicates when batteries must be replaced to prevent server crashes.




Technical specifications:


Model		H1KS	H2KS	H3KS
Rated power	VA/W	1KVA/0.7KW	2KVA/1.4KW	3KVA/2.1KW
Input	Nominal voltage	220VAC
	Voltage range	115~300VAC
	Frequency range	46~54Hz(default), user adjustable within 40~60Hz
	Power efficiency	0.97
	Connection	IEC320-10A inlet		IEC320-16A inlet
Output	Voltage	220VAC±2%
	Frequency	46~54Hz or 50Hz±0.2(line mode) 50Hz±0.2Hz(battery mode)
	Waveform	Pure sine wave
	Distortion	3%	4%
	Overload capability	108%~150% for 30 sec., 150% for 300ms
	Current crest ratio	3:1
	Connection	IEC320*4	IEC320*6	IEC320*3 and terminal block
Battery	Type	Sealed, maintenance free, lead-acid
	Quantity	3 pieces	6 pieces	8 pieces
	Back-up time(full load)	5 min	9 min	5 min
	Recharge time	5 hrs to 90% of capacity after full load discharge
Bypass	Automatic transfer	On overload and UPS failure
	Before UPS power-on	Default “NO”, user adjustable to “YES”
	Voltage range	80~264VAC(default), user adjustable within 80~286VAC
Transfer time		0 ms; less than 4ms from inverter to bypass and vice versa
LED indicators	Status	Load level/battery level, battery , utility power, inverter, bypass, overload, fault
Audible alarm		Bypass, on battery mode, battery low, overload, fault
Acoustic noise	At 1 meter distance	45 dB	50 dB
Communication	DB-9 port	RS-232 serial interface
	Intelligent slot	Options: Webpower, AS400 card or Winpower CMC
Network surge protection		RJ45 I/O port available for network or fax/modem
Environmental	Operating temperature	0~40°C
	Operating humidity	20~90% non-condensing
Weight	Net(Kg)	13	31.5	32
Dimension	WxDxH(mm)	145x400x220	192x460x348



Model			H1KL	H2KL	H3KL
Rated power	VA/W		1KVA/0.7KW	2KVA/1.4KW	3KVA/2.1KW
Input	Nominal voltage		220VAC
	Voltage range		115~300VAC
	Frequency range		46~54Hz(default), user adjustable within 40~60Hz
	Power factor		0.97
	Connection		IEC320-10A inlet		IEC320-16A inlet
Output	Voltage		220VAC±2%
	Frequency		46~54Hz or 50Hz±0.2(line mode) 50Hz±0.2Hz(battery mode)
	Waveform		Pure sine wave
	Distortion		3%	4%
	Overload Capability		108%~150% for 30 sec., 150% for 300ms
	Current crest ratio		3:1
	Connection		IEC320-10A*4	IEC320-10A*6	IEC320-10A*3 and terminal block
Battery	Type		Sealed, maintenance free, lead-acid
	Nominal DC voltage		36VDC	96VDC		96VDC
	Back-up time		Depends on the capacity of the external battery bank
	Connection		External battery socket
Bypass	Automatic transfer		On overload and UPS failure
	Before UPS power-on		Default “NO”, user adjustable to “YES”
	Voltage range		80~264VAC(default), user adjustable within 80~ 286VAC
Transfer time			0 ms; less than 4 ms from inverter to bypass and vice versa
LED indicators		Status	Load level/battery level, battery, utility power, inverter, bypass, overload, fault
Audible alarm			Bypass, on battery mode, battery low, overload, fault
Acoustic noise		At 1 meter distance	45 dB	50 dB
Communication		DB-9 port	RS-232 serial interface
		Intelligent slot	Options: WebPower, AS400 card or WinPower CMC
Network surge protection			RJ45 I/O port available for 10 base-T network or fax/modem
Environmental		Operating temperature	0~40°C
		Operating humidity	20~90% non-condensing
Weight		Net(Kg)	7	13.5	14
Dimension		W x D x H(mm)	145x400x220	192x460x348
